Compact and easy
to use Real-time PCR instrument
The CFX96™ Dx Real-time PCR System can detect 5 different fluorescent dyes simultaneously. Thus, it is suitable
for multi-pathogens detection in one clinical sample.
The solution for high multiplex real-time PCR detection
Get great results right away
Fast and accurate temperature control is possible that be shortening total test time
Fit experiments into your schedule
It is possible to check the result within 30 minutes by fast thermal circulation device, accurate test results are obtained by measuring the fluorescence signal of each well individually.
High multiplex test
The CFX96 can use up to five channels simultaneously. Therefore, we are realizing high multiplex test by combining Seegene product which can confirm multiple results per channel.
Easily expand your throughput when needed
Up to 4 instruments can be controlled by a single computer and various fluorescent materials can be used according to user's convenience.
Results of real-time PCR detection by using CFX96™ Dx
Results of Anyplex™ MTB/NTM Real-time Detection
MTB positive
MTB & NTM co-infection
NTM positive
Negative
Specification
| Sample Capacity | 96 |
| Temp. Range | 0~100ºC |
| Maximum Ramp Rate | 5ºC/sec |
| Average Ramp Rate | 3.3ºC/sec |
| Detection Channel | 6 |
| Dimensions | 330 (W)x460 (D)x360 (H) mm |
| Weight | 21kg |
| Maximum Power Consumption | 850W |
| Ordering Information |
1845097-IVD (CFX96™ IVD Optical Reaction Module)
, 1841000-IVD (C1000 Thermal Cycler) |
